NAIM FLATCAP 2 - NAC 282 Connection to Hi-cap and NAPSC; NAC 282 Connection to Two Hi-caps (or Flatcap 2 s)

7
NAC 282 connection to Hi-cap and NAPSC
Or NAC 282 connection to two Hi-caps (or Flatcap 2s)
mains input
or with extra Flatcap 2 or Hi-cap for SNAXO or IXO5
power mains input
to SNAXO or IXO5 (using
external power supply)
for CD5, headline or stageline
(additional) interconnects required
cable
direction
marker
mains input
to stereo power amplifiers
to mono or dual mono
power amplifiers
4 to 4 pin DIN
240° 5 to 5 pin DIN
Interconnect Cables
Hi-cap
NAC 282
mains
input
to stereo power amplifiers
or to IXO5 using internal power supply
to mono or dual mono
power amplifiers
to NAPSC
Hi-cap Hi-cap
Flatcap 2
NAC 282
mains input
NAPSC
