NAIM N-VI - Page 20

E18
Programme Material
Analogue
Stereo
Dolby Digital
Dolby Digital
DTS (Digital)
PCM (digital)
(2/0)
(3/2.1)
(3/2.1)
Yes
N/A
N/A
N/A
N/A
N/A
Yes
Yes
Yes
Yes
N/A
Yes
Yes
Yes
Yes
N/A
Yes
Yes
No
No
N/A
Yes
Yes
No
No
N/A
Yes
Yes
No
No
N/A
Yes
Yes
No
No
N/A
Yes
Yes
Yes
Yes
Decode
Modes
Analogue Direct
Mono
Stereo
Dolby PL II Music
Dolby PL II Movie
DTS Neo:6 Cinema
DTS Neo:6 Music
Auto
Table 9.6
Decode Modes - Availability with Programme Material Types
n-Vi
Operation
Note:
Channel schemes are also expressed by terms such as
“5.1” or “3/2.1” Taking 5.1 as an example, the “5” refers to the
number of conventional speaker channels and the “.1” refers to a
subwoofer. In 3/2.1 the “3” refers to the number of front channels
employed (in this case, left, right and centre), the “2” refers to the
number of surround channels and the “.1” refers to a subwoofer.
Tables 9.5 and 9.6 refer to channel schemes in this manner.
Speaker Channels
Left
Centre
Right
Left
Right
Subwoofer
Front
Front
Surround
Surround
Yes
Yes
Note*
Yes
Yes (“small” or Bass Mix selected)**
Yes
Yes
Yes (“small” or Bass Mix selected)**
Yes
Yes
Yes
Yes
Yes
Yes (“small” or Bass Mix selected)**
Yes
Yes
Yes
Yes
Yes
Yes (“small” or Bass Mix selected)**
Yes
Yes
Yes
Yes
Yes
Yes (“small” or Bass Mix selected)**
Yes
Yes
Yes
Yes
Yes
Yes (“small” or Bass Mix selected)**
Yes
Yes
Yes
Yes
Yes
Yes
**Note:
The subwoofer
channel will only operate
if Bass Mix (Paragraph
7.5.3) or “small” speakers
(Paragraph 7.6.1) are
selected.
Source
Format
Analogue
Digital Stereo
Digital Stereo
Digital Stereo
Digital Stereo
Digital Stereo
Digital Stereo
Dolby Digital/DTS 5.1
Table 9.5
Source Material, Decode Modes and Channel Schemes
Decode
Mode
Analogue Direct
Mono
Stereo
Dolby PL II Music
Dolby PL II Movie
DTS Neo:6 Cinema
DTS Neo:6 Music
Auto (5.1 source)
*Note:
An alternative
dedicated subwoofer (or dual
input subwoofer) can be
connected via the analogue
output or speaker output
sockets if required.
