NAMCO Final Furlong 2 - Page 11

Replacing the Game PCB
1. Disconnect all the connectors on the Game PCB including the fan connectors.
Note: Some of the cables will be replaced with new cables (see illustration below)
2. Remove the 2off pozi head screws (M6x25) from the right hand end of the Game
PCB. slacken the 2off pozi head screws (M6x25) on the left hand end and remove
the Game PCB.
These cables
will not be used
on the new
game PCB
Pozi head screw
(M6x25)
