4. Pull the ride assembly away from the monitor cabinet only sufficient to reach the
connectors. (
Take care not to stretch the wiring harness.)
5. Disconnect the connectors and move the ride assembly completely away from the
monitor cabinet.
Removing the Header Assembly
The header assembly is high and has a forward centre of gravity, so it is important
that at least
two people are used to remove or fit the Header Assembly.
1. Remove 2off pozi head screws (M4x12), with flat and spring washers, and remove
the connector cover plate.
2. Disconnect the connector.
To Next Page
