Nanni N3.21 - Main Parts of the Engine

3
1. Alternator
2. Alternator belt
3. Starter
4. Air fi lter
5. Injection pump
6. Acceleration control
7. Fuel fi lter
8. Water injection exhaust elbow
9. Oil fi ller port
10. Oil drain port
11. Oil gauge
12. Oil fi lter
13. Heat exchanger
14. Coolant fi ller port
15. Sea-water pump
16. Exchanger drain plug
17. Coolant pump
18. Flexible suspensions
19. Gearbox
20. Hoisting rings
21. Anode
Non-binding photographs. The coupled equipment and accessories can vary according to your level of equipment.
9
4
14
1
17
15
12
3
16
13
8
21
20
6
5
11
19
2
7
18
10
18
20
18
Main parts of the engine
