Safety icons
Several stickers are fixed directly
on the engine. They are intended
to help you to quickly identify the
location of certain components
and avoid possible hazards when
working on the engine.
Ensure these stickers are always
visible and change them if neces-
sary.
Refers to important infor-
mations and instructions to follow
before handling the engine.
Indicates possible electrical
hazards.
This icon indicates a risk of
fire.
Indicates hot parts entailing
substantial risks of burns.
Indicates an area containing
pressurised fluids.
Stipulates that no flames or
sparks should be created in the
vicinity.
Indicates hazardous rotating
parts.
Indicates the de-aeration
orifice(s) (air bleed).
Indicates where to check the
coolant level.
Indicates where to check the
engine oil level.
Indicates the coolant drain
orifice.
Indicates the oil drain orifice.
