Nanni N4.85 - Technical Data

61
MODEL N4.85 N4.100
ENGINE CHARACTERISTICS
Type 4 strokes Diesel
Max. power - kW (hp)* 62.5 - 85 73.6 - 100
Number of cylinders / Arrangement 4 in line
Displacement (cm
3
)3053
Bore and stroke (mm) 94 - 110
Air intake Turbo Turbo & Intercooler
Compression ratio 20:1
Idle speed - clutch disengaged
(rpm)*
875
Rated engine speed @ Max power
(rpm)*
2800
Max RPM at wide open throttle
(rpm)*
3020
Recommended cruising speed (rpm) 2240 ~ 2520
Weight without gearbox (kg) 328 335
Valve clearance (engine cold) - in-
take (mm)
0,13 ~ 0,17
Valve clearance (engine cold) - ex-
haust (mm)
0,13 ~ 0,17
Direction of rotation, view from
flywheel
Counter clockwise
TECHNICAL DATA
9
