S06 COMPONENTS
ENGINE MAIN COMPONENTS
NOTE !
Minor engine details may not be exactly as shown. Some components may not be part of the engine ordered. Not
binding pictures.
P/N COMPONENTS
1 Fuses box
2 Relay box
3 Waterbox heat exchanger
4 Heat exchanger drain plug
5 Waterbox cap
6 Water inlet
7 Seawater pump
8 Diagnostic socket
9 Priming manual pump
10 Alternator
11 Air lter 1
12 Air lter 2
13 Charge air cooler
14 ECU
15 EDU
16 Turbocharger 1 heat sleeve protected
17 Turbocharger 2 heat sleeve protected
18 Turbocharger actuator
19
Turbocharger mixer
20
Exhaust manifold drain plug
21
Exhaust elbow
22
Cooling elbow air drain
23
Flywheel
24
Engine mount
25
Oil lter
26 Oil ller cap
27 Oil dipstick
28 Pan oil cooler
29 Oil cooler inner core
30 Water inlet
