7
PGM Wiring
The PGM is a switched negative output that is
activated depending on the programming op-
tion(s) that have been selected [08], [23] - [25].
Connect the device controlled by the PGM be-
tween +PWR and the PGM terminal (maximum
load of 50 mA).
.H\SDG 2SHUDWLRQ
Keypad zone LEDs indicate zone status.
ARMED, STATUS and
SYSTEM LEDs provide
system status. The keypad sounder provides
feedback beeps for correct and incorrect entries.
Keypad Sounder
3
QUICK BEEPS
Panel Armed (System ON)
Chime ON
Fault Find Mode ON
Keypad Sounder ON
Zone Bypassed
6
QUICK BEEPS
Panel Disarmed (System OFF)
Chime OFF
Fault Find Mode OFF
Keypad Sounder OFF
Zone Un-Bypassed
1
SECOND
-
STEADY TONE
Incorrect Code Entered
Invalid key entry
4
LONG BEEPS
(
PRIORITY CONDITION
)
1. Entering an Arm Code with a faulted zone
(Not an Auto-Bypass Reentry Zone).
2. Entering an Arm Code when the Bell or
PGM is ON (Bell and PGM will turn OFF).
Keypad LEDs
ARMED LED DEFINITION
Armed ON
Instant Mode Rapid Flash
Zone in Alarm Flashing
STATUS LED DEFINITION
Ready to be Armed ON
Zone faulted OFF
TROUBLE LED DEFINITION
AC Failure Flashing
System Trouble(s) ON
ZONE LED DEFINITION
Faulted Zone ON
Bypassed Zone Slow Flash
Zone in Alarm Flashing
3DQHO 2SHUDWLRQ
Arming (System ON)
Before arming the system close all protected
zones (unless programmed as Auto-Bypass
Reentry Zones). Enter a 4-digit Arm/Disarm
code, followed by the
key, the keypad will
provide a feedback beep for each key pressed.
If a valid Arm/Disarm code is entered, the key-
pad will beep 3 times. If an incorrect Arm/Disarm
code is entered, the keypad will sound a 1-
second tone indicating an incorrect entry.
Arming without Entry Delay (Instant
Mode)
Enter the
key to eliminate the entry delay.
The ARMED LED will flash rapidly to indicate the
panel is in Instant Mode. If an Exit/Entry Zone is
tripped while the panel is in Instant Mode the
panel will go into alarm immediately.
Wi879a
page 7
Tuesday, September 16, 1997 08:16
