NAPCO Gemini C-Series Control Panel Installation Instructions--Volume 2
Page 58 Installation Instructions, Volume 2
NAPCO Programming Feature and (2) the CP-01 Requirement:
Swinger Shutdown (NAPCO Programming Feature): Program a zone with this feature to allow only three alarms
per arming period. Auto-Reset must also be programmed for the zone for this feature to work.
Swinger Shutdown (CP-01 Requirement): To meet CP-01, all non-Fire zones must not be programmed for Auto-
Reset. A zone not programmed for Auto-Reset will trip only one alarm per arming period. The panel leaves the factory
with no zones programmed for Auto-Reset.
System Descriptions of the System Assignment (Properties).
The "System Descriptions" screen in PCD-Windows Quickloader allows you to enter a description for each system output.
System Options of the System Assignment (Properties).
The "System Options" tab in PCD-Windows Quickloader allows various system options to be selected or deselected. System
Options are grouped by category (depending on panel) and are shown in the below figures. Each feature can be selected or
deselected by clicking the check box in front of the feature.
System Reporting and Outputs
System Troubles / Events (Test Timer, Memory Fail, Low Battery, Burg Low Battery, AC Fail, EZM Tamper, Sensor
Watch, Telco Line 1 Failure, Telco Line 2 Failure, Digital Dialer Test, Service Message, Program Change, Housing
Tamper, Telemetry Trouble, Telemetry Failure, Ground Fault, ACM Power Failure, ACM Low Battery) can trip any out-
put (Pulsed Burg, Auxiliary, etc.). Note: RF TROUBLE will report for RF Low Battery, RF Supervision Failure or GEMC-
BSLC-DT Self-Test Failure.
Tamper
EZM Tamper
Keypad Tamper
RF Tamper
Bell Alarm on Tamper Options (Required for Mercantile Burglary):
ENABLE BURG POINT SOUND BURG ALARM ON (RF-XMIT PNT/BSLC PNT-TAMPER) ONLY IF IN ZONE ARMED
ENABLE BURG POINT REPORT TAMPER ON (RF-XMIT PNT/BSLC PNT TAMPER) ONLY IF ZONE ARMED
ENABLE BURG RF RECEIVER TAMPER SOUND BURG ALARM ONLY IF ANY AREA ARMED
Removing the cover of an expansion zone module will cause the sounder to pulse and the "SYS/TBL" reminder to flash. The
keypad will display "E13-NN BURG EZM TAMPER", where "NN" denotes the module number. Press the RESET button to si-
lence the sounder ("SYSTEM READY" will display). Correct the problem, then select RESET SYSTEM TBL to manually reset the
system trouble display. Removing a keypad from the wall causes a similar system trouble indication. The keypad will display
"E11-NN BURG KPD TAMPER", where "NN" denotes the keypad number. Press the RESET button to silence the sounder
("SYSTEM READY" will display). To manually reset the system trouble, correct the problem then select "RESET SYSTEM TBL".
Note: If either of the tamper conditions is not corrected within 5 minutes, the system trouble will again display at the keypad.
In addition:
A Tamper condition can be programmed to activate the burglary bell and/or report using its associated system Report
Code.
In wireless installations, when displaying RF transmitter status, a "Tamper" indication denotes that the transmitter case is
open.
In Commercial Burglary installations, the Tamper must generate the audible alarm if the system is armed. Program in
PCD-Windows Quickloader System Assignment screen, System Reporting and Outputs tab, for both EZM Tamper and
Housing Tamper, check "Burg Bell" (column).
TCP/IP Panel/Site Initiated Functions (see Fire Glossary)
Telco Fail See Enable Telephone Line-Fault Test
Telco Fail Only When Armed
The Telco Line Cut Monitor will only be active when the system is armed.
Telemetry Failure
If the device connected to the on-board Serial Port is not able to carry out its intended function, it can send a signal to the
control panel, and a Telemetry Trouble system trouble will result. On the PCD-Windows System Features screen, enable Te-
lemetry Failure: = XF to report on alarm or activate and output. On the PCD-Windows System Reporting Codes screen, pro-
gram a reporting code for Telemetry Failure.
Keypad readout will be: E59-00 SERVICE
BURGLARY GLOSSARY
