NAPCO XP-600 Express Series Programming Instructions

6
7HOHSKRQH 1XPEHU  3URJUDPPLQJ
30
Subscriber ID Number
[0] Disabled
[1] Ademco Slow
[2] Radionics Slow
[3] Silent Knight Fast
[4] Universal High Speed
[5] Reserved
[6] Point ID
[7] Pager
32
Receiver Format
(4)
31
Telephone Number 1
N
OTE
:
Requires features to be enabled, see block [20].
N
OTE
1:
A fixed Dial Tone Detection (E) is included prior to the
Dialing Prefix
(Block
Number 44)
.
Programming an E is not required for Telco 1, Telco 2 and
Telco 3. If dial tone detection is not desired select
No Dial Tone Detection
in
Communicator Features (Block Number 46). Program a D if a 4 second
delay is required.
Includes Bell Cut, Fire Trouble, Receiver Fail-to-Respond, Receiver Tamper,
Receiver JAM, Transmitter Low Battery, Transmitter Supervisory Faliure,
Wireless Smoke Low Battery, Wireless Smoke Supervisory Failure.
ZONE 3 TX LOW BATTERY “RF TRAN LOW BAT, ZN03”
SMOKE 2 LOW BATTERY “RF TRAN LOW BAT, ZN10”
N
OTE
2:
Default
OFF
OFF
OFF
OFF
OFF
OFF
39
Opening Closing Report, Telco 1
Zn 1 LED ON = User 1 Reporting
Zn 2 LED ON = User 2 Reporting
Zn 3 LED ON = User 3 Reporting
Zn 4 LED ON = User 4 Reporting
Zn 5 LED ON = User 5 Reporting
Zn 6 LED ON = User 6 Reporting
Default
ON
ON
ON
ON
ON
ON
34
Zone Report, Telco 1
Zone 1
Zone 2
Zone 3
Zone 4
Zone 5
Zone 6
Default
OFF
OFF
OFF
OFF
OFF
OFF
35
Zone Restore Report, Telco 1
Zone 1
Zone 2
Zone 3
Zone 4
Zone 5
Zone 6
Default
OFF
OFF
OFF
ON
36
System Reporting, Telco 1
Zn 1 LED ON = *KP Fire
(

)
Zn 2 LED ON = *KP AUX
(

)
/
Ambush
Zn 3 LED ON = *KP Panic
(

)
Zn 4 LED ON = Test Timer
*See Note 1
Default
ON
ON
OFF
OFF
37
System Reporting, Telco 1
Zn 1 LED ON = AC Fail Report
(15 min. report delay)
Zn 2 LED ON = Low Battery Report
Zn 3 LED ON = *Trouble Report
Zn 4 LED ON = Fire Report
*See Note 2
Default
OFF
OFF
OFF
OFF
38
System Restore Report, Telco 1
Zn 1 LED ON = AC Restore Report
Zn 2 LED ON = Battery Restore Report
Zn 3 LED ON = Trbl Restore Report
Zn 4 LED ON = Fire Restore Report
Default
OFF
OFF
ON
OFF
33
Receiver Options
Zn 1 LED ON = 2300 Hz Handshake/Kissoff
Zn 2 LED ON = Sumcheck
Zn 3 LED ON = Single Digit
Zn 4 LED ON = No Handshake
Wi847c
page 6
Tuesday, September 16, 1997 08:35
