9
5HSRUW &RGHV
60
Zone Report Codes
Zone 1 Alarm Code
(3)
Zone 2 Alarm Code
(3)
Zone 3 Alarm Code
(3)
Zone 4 Alarm Code
(3)
Zone 5 Alarm Code
(3)
Zone 6 Alarm Code
(3)
The second digit of the
Re-
port Code
is the number of
the zone that is reporting.
For example zone 5 report
code (default of 3) would be
35.
61
Point ID Report Codes
Zone 1 Alarm Code
(3)
Zone 2 Alarm Code
(3)
Zone 3 Alarm Code
(3)
Zone 4 Alarm Code
(3)
Zone 5 Alarm Code
(3)
Zone 6 Alarm Code
(3)
1FIRE
2 PANIC
3 BURGLARY
4 HOLDUP
5 GENERAL ALARM
6 RESERVED
7 GAS ALARM
8 HEAT ALARM
9 RESERVED
A AUXILIARY
B 24 HOUR ALARM
62
Zone Codes
Zone 1, 2, 3, 4, 5 & 6 Restore Code
(E)
Zone 1, 2, 3, 4, 5 & 6 Trouble Code
(
F)
63
System Report Codes
Keypad Fire (
)
(1) (1)
Keypad AUX (
)
(2) (3)
Keypad Panic (
)
(2) (1)
Test Timer
(F) (F)
AC Fail
(F) (9)
Low Battery
(F) (8)
*Trouble
(F) (1)
Fire
(1) (1)
64
System Restore Code
(E)
65
Opening and Closing Code
(C)
Closing Code
(B)
Opening Code
66
Ambush Report Code
(2) (2)
Enhanced Communicator Features
Includes Bell Cut, Fire Trouble, Receiver Fail-to-Respond, Receiver Tamper,
Receiver JAM, Transmitter Low Battery, Transmitter Supervisory Faliure, Wire-
less Smoke Low Battery and Wireless Smoke Supervisory Failure.
N
OTE
1:
N
OTE
:
*
See Note 1
Default
OFF
OFF
OFF
OFF
67
Telephone Number 1
Zn 1 LED ON = Opening after Alarm
(Cancel Code)
Zn 2 LED ON = Conditional Closing
Zn 3 LED ON =
Reserved
Zn 4 LED ON = Reserved
Default
OFF
OFF
OFF
OFF
68
Telephone Number 3
Zn 1 LED ON = Opening after Alarm
(Cancel Code)
Zn 2 LED ON = Conditional Closing
Zn 3 LED ON =
Reserved
Zn 4 LED ON = Reserved
Wi847c
page 9
Tuesday, September 16, 1997 08:35
