Napoleon BGD36PTR Installation And Operation Instructions

33
W415-0210 / R / 02.27.08
GD112 - FLAT ROOF
32 W670-0006 AIR TERMINAL
33 W490-0073 4/7 INNER/OUTER SLEEVE
34 W010-0567 ROOF SUPPORT
35 W263-0056 ROOF FLASHING
36 W170-0063 STORM COLLAR
37* W175-0001 4" COUPLER
38* W175-0013 7" COUPLER
39 L36K LOUVRE KIT -
UPPER & LOWER - BLACK
39 LK36AB LOUVRE KIT - ANTIQUE BRASS
39 LK36PB LOUVRE KIT - POLISHED BRASS
39 LK36SS LOUVRE KIT - BRUSHED STAINLESS STEEL
40* W690-0001 MILLIVOLT THERMOSTAT
41* W660-0011 REMOTE CONTROL -
ADVANTAGE PLUS
42* W500-0096 FIRESTOP SPACER
43* W500-0103 TERMINAL EXTENSION PLATE
44 GD-301 HEAT GUARD
45* W10-0370 WALL SUPPORT ASSEMBLY
46* W660-0013 MODULATING REMOTE
47* W175-0053 DURA-VENT ZERO CLEARANCE ADAPTOR
48* W361-0016 GLOWING EMBERS
49 W585-0071 VENT PIPE COLLAR
50 W585-0072 VENT PIPE SHIELD
51 GZ550-1KT BLOWER KIT
52* GD36 THERMOSTATIC SENSOR CONTROL KIT
FOR USE WITH GD65 ONLY
53 HOIK-2 HERITAGE ORNAMENTAL INSETS - BLACK
53 HOIG-2 HERITAGE ORNAMENTAL INSETS - GOLD PLATED
53 HOIKG-2 HERITAGE ORNAMENTAL INSETS - BLACK GOLD PLATED
53 HOIBC-2 HERITAGE ORNAMENTAL INSETS - BRUSHED COPPER PLATED
53 HOIBG-2 HERITAGE ORNAMENTAL INSETS - BRUSHED GOLD PLATED
54 DOIK-1 DIAMOND ORNAMENTAL INSETS - BLACK
54 DOIG-1 DIAMOND ORNAMENTAL INSETS - GOLD PLATED
54 DOIKG-1 DIAMOND ORNAMENTAL INSETS- BLACK GOLD PLATED
54 DOIBC-1 DIAMOND ORNAMENTAL INSETS- BRUSHED COPPER PLATED
54 DOIBG-1 DIAMOND ORNAMENTAL INSETS- BRUSHED GOLD PLATED
55 GOIK-1 GOTHIC ORNAMENTAL INSETS - BLACK
55 GOIG-1 GOTHIC ORNAMENTAL INSETS - GOLD PLATED
55 GOIKG-1 GOTHIC ORNAMENTAL INSETS - BLACK GOLD PLATED
55 GOIBC-1 GOTHIC ORNAMENTAL INSETS - BRUSHED COPPER PLATED
55 GOIBG-1 GOTHIC ORNAMENTAL INSETS - BRUSHED GOLD PLATED
56 SOIK-1 SEASHELL ORNAMENTAL INSETS - BLACK
56 SOIG-1 SEASHELL ORNAMENTAL INSETS - GOLD PLATED
56 SOIKG-1 SEASHELL ORNAMENTAL INSETS - BLACK GOLD PLATED
56 SOIBC-1 SEASHELL ORNAMENTAL INSETS -BRUSHED COPPER PLATED
56 SOIBG-1 SEASHELL ORNAMENTAL INSETS - BRUSHED GOLD PLATED
57 EOIK-1 ECLIPSE ORNAMENTAL INSETS - BLACK
57 EOIG-1 ECLIPSE ORNAMENTAL INSETS - GOLD PLATED
57 EOIKG-1 ECLIPSE ORNAMENTAL INSETS - BLACK GOLD PLATED
57 EOIBC-1 ECLIPSE ORNAMENTAL INSETS - BRUSHED COPPER PLATED
57 EOIBG-1 ECLIPSE ORNAMENTAL INSETS - BRUSHED GOLD PLATED
58 DK36-R DOOR KIT, RECTANGULAR - BLACK
58 DK36-RG DOOR KIT, RECTANGULAR - GOLD PLATED
59 DK36-A DOOR KIT, ARCHED - BLACK
59 DK36-AG DOOR KIT, ARCHED - GOLD PLATED
60 DK36-W DOOR KIT, WEBBED - BLACK
60 DK36-WG DOOR KIT, WEBBED - GOLD PLATED
61 GA-566 HOT AIR KIT
62 GA-72 HOT AIR EXHAUST KIT
63 GA-70 EXTENSION KIT 5FT
64* RP-KT RESTRICTOR PLATE KIT
65* VS47KT VENT SLEEVE
66* W573-0002 HIGH TEMPERATURE SEALANT
67* W573-0007 HIGH TEMPERATURE SEALANT
# PART NO. DESCRIPTION
1* W225-0058 BLACK DOOR FRAME
2 W357-0001 PIEZO IGNITER
3 W680-0004 THERMOPILE
4 W680-0005 THERMOCOUPLE **
5* W010-0800 PROPANE GAS PILOT ASSEMBLY
5* W010-0801 NATURAL GAS PILOT ASSEMBLY
6* W455-0069 NATURAL GAS PILOT INJECTOR
6* W455-0067 PROPANE GAS PILOT INJECTOR
7 W725-0025 NATURAL GAS VALVE
7 W725-0026 PROPANE GAS VALVE
8* W385-0245 NAPOLEON LOGO
9* W750-0112 20FT OF WIRE
10* W010-0538 FLUE CAP c/w GASKET
11* W010-0539 FLUE PIPE ASSEMBLY c/w GASKET
12 W010-0764 PAN BURNER
13* GL-639 LOG SET
14* W361-0016 GLOWING EMBERS
15* W550-0001 CHARCOAL EMBERS
16 W135-0183 BACK LOG (#1)
17 W135-0184 LEFT MIDDLE LOG (#2)
18 W135-0185 RIGHT MIDDLE LOG (#3)
19 W135-0186 LEFT CROSSOVER LOG (#4)
20 W135-0187 MIDDLE CROSSOVER LOG (#5)
21 W135-0188 RIGHT CROSSOVER LOG (#6)
22 W010-0454 GLASS C/W GASKET
23 W010-0516 BLACK DOOR C/W GLASS
Contact your dealer for questions concerning prices and availability
of replacement parts. Normally all parts can be ordered through your
Napoleon® dealer or distributor.
When ordering replacement parts always give the following
information:
1. MODEL & SERIAL NUMBER OF FIREPLACE
2. INSTALLATION DATE OF FIREPLACE
3. PART NUMBER
4. DESCRIPTION OF PART
5. FINISH
6. TOP OR REAR VENT
REPLACEMENTS
COMMON COMPONENTS
COMMON ACCESSORIES
GD220 (5 FT)
24* W010-0397 4" FLEXIBLE VENT PIPE - (5 FT) C/W SPACERS
25* W410-0017 7" FLEXIBLE VENT PIPE - (5 FT)
GD330 (10 FT)
26* W410-0018 7" FLEXIBLE VENT PIPE -(10 FT)
27* W010-0300 4" FLEXIBLE VENT PIPE -(10
FT) C/W SPACERS
28* W010-0370 WALL SUPPORT ASSEMBLY
29 PERISCOPE - GD201
30 WALL TERMINAL KIT - GD222
31* 1/12 TO 7/12 PITCH - GD110
32 W670-0006 AIR TERMINAL
33 W490-0073 4/7 INNER/OUTER SLEEVE
34 W010-0567 ROOF SUPPORT
35 W263-0054 ROOF FLASHING
36 W170-0063 STORM COLLAR
GD111 - 8/12 TO 12/12 PITCH
32 W670-0006 AIR TERMINAL
33 W490-0073 4/7 INNER/OUTER SLEEVE
34 W010-0567 ROOF SUPPORT
35 W263-0055 ROOF FLASHING
36 W170-0063 STORM COLLAR
COMMON FLEXIBLE VENT KITS
COMMON TERMINAL KITS
COMMON ROOF TERMINAL KITS
Failure to position the parts in accordance with these diagrams or
failure to use only parts specified approved with this appliance may
result in property damage or personal injury.
!
WARNING
!
WARNING
**This is a fast acting thermocouple. It is an integral safety
component. Replace only with a fast acting thermocouple supplied
by Wolf Steel Ltd.
* IDENTIFIES ITEMS WHICH ARE NOT ILLUSTRATED. FOR FURTHER
INFORMATION, CONTACT YOUR NAPOLEON® DEALER.
FOR WARRANTY REPLACEMENT PARTS, A PHOTOCOPY OF THE
ORIGINAL INVOICE WILL BE REQUIRED TO HONOUR THE CLAIM.
NorthlineExpress.com
http://www.northlineexpress.com
Toll-Free 1-866-667-8454

Napoleon BGD36PTR Specifications

General

Brand	Napoleon
Model	BGD36PTR
Category	Indoor Fireplace
Language	English
