2
W415-0210 / R / 02.27.08
Minimum Enclosure Clearances
Minimum Mantel Clearances
Nailing Tab Installation
27-28 FINISHING
Door Removal & Installation
Door Glass Replacement
L36 Louvre Installation
Log Placement
Logo Placement
29
OPTIONAL BLOWER INSTALLATION
30 OPTIONAL FAN INSTALLATION
OPTIONAL THERMOSTATIC SENSOR
31 OPERATION / MAINTENANCE
Operating Instructions
Maintenance
30 ADJUSTMENTS
Pilot Burner Adjustment
Venturi Adjustment
32-34 REPLACEMENTS
Ordering Replacement Parts
Replacement Parts
Accessories
35-36 TROUBLE SHOOTING GUIDE
37 SERVICE HISTORY
38 NOTES
PG 2-5 INTRODUCTION
Warranty
General Instructions
General Information
Care of Glass and Plated Parts
Specifi cations
5-16 VENTING
Venting Lengths
Vent Installations
Typical Vent Installations
Special Vent Installations
Minimum Air Terminal Location Clearances
Venting Application Flow Chart
Venting Specifi cations
Pre-Installation Preparation
17-26 INSTALLATION
Wall and Ceiling Protection
Horizontal Installation
Vertical Installation
Using Flexible Vent Components
Fireplace Vent Connection
Using Rigid Vent Components
Vertical Venting Installation
Restricting Vertical Vents
Mobile Home Installation
Gas Installation
Optional Wall Switch Installation
Framing
NOTE: CHANGES, OTHER THAN EDITORIAL, ARE DENOTED BY A VERTICAL LINE IN THE MARGIN.
• Do not burn wood or other materials in this fi replace.
• Adults and especially children should be alerted to the hazards of high surface temperatures and should stay away to avoid burns or
clothing ignition. Supervise young children when they are in the same room as the fi replace.
• Clothing or other fl ammable material should not be placed on or near the fi replace.
• Due to high temperatures, the fi replace should be located out of traffi c and away from furniture and draperies.
• Ensure you have incorporated adequate safety measure to protect infants/toddlers from touching hot surfaces.
• Even after the fi replace is out, the glass and/or screen will remain hot for an extended period of time.
• Check with your local hearth specialty dealer for safety screens and hearth guards to protect children from hot surfaces. These screens
and guards must be fastened to the fl oor.
• Any safety screen or guard removed for servicing must be replaced prior to operating the fi replace.
• It is imperative that the control compartments, burners and circulating blower and its passageway in the fi replace and venting system
are kept clean. The fi replace and its venting system should be inspected before use and at least annually by a qualifi ed service person.
More frequent cleaning may be required due to excessive lint from carpeting, bedding material, etc. The fi replace area must be kept clear
and free from combustible materials, gasoline and other fl ammable vapours and liquids.
• Under no circumstances should this fi replace be modifi ed.
• This fi replace must not be connected to a chimney fl ue pipe serving a separate solid fuel burning appliance.
• Do not use this fi replace if any part has been under water. Immediately call a qualifi ed service technician to inspect the fi replace and to
replace any part of the control system and any gas control which has been under water.
• Do not operate the fi replace with the glass door removed, cracked or broken. Replacement of the glass should be done by a licensed
or qualifi ed service person.
• Do not strike or slam shut the fi replace glass door.
• This fi replace uses and requires a fast acting thermocouple. Replace only with a fast acting thermocouple supplied by Wolf Steel Ltd.
• Pressure relief doors must be kept closed while the fi replace is operating to prevent exhaust fumes containing carbon monoxide, from
entering into the home. Temperatures of the exhaust escaping through these openings can also cause the surrounding combustible
materials to overheat and catch fi re.
• Only doors / optional fronts certifi ed with the unit are to be installed on the appliance.
TABLE OF CONTENTS
RETAIN THIS MANUAL FOR FUTURE REFERENCE
!
WARNING
