45
Specifi-
cations
Miscellaneous
All the data specified here is valid under the
following conditions unless otherwise stated:
✓ Sinusoidal signals
✓ The instrument is located in the far field
region of the source
✓ Ambient temperature: 23°C 3°C
✓ Relative humidity: 25% to 75%
The data include all relevant partial errors for
calculating the overall error to IEC 359.
Alarm threshold at the calibration
frequency
50% of standard value 1.0 dB,
individually calibrated.
Calibration frequency: 100 MHz
Visible display
Display using 4 LEDs
Thresholds at 12.5%, 25%, 50% and
100% of standard value
The display is calibrated in terms of
relative power flux density. 50% of the
power flux density of the standard
corresponds to an E-field or H-field
strength of 70.7% of the limit value in the
relevant standard.
The E- and H-field components are
measured simultaneously. The largest
value is displayed.
