National Instruments 622 Series User Manual

2-4 | ni.com
Chapter 2 DAQ System Overview
Table 2-1. 68-Pin M Series Device/Module Cables and Accessories
Cables and Accessories
Type
PCI, PCI Express,
PXI, PXI Express
Devices and Modules
USB Mass Termination Devices
622x/625x/
628x
Connector 0
6224/6229/
6254/6259/
6284/6289
Connector 1
6225/6255
Connector 1
622x/625x/
628x
Connector 0
6229/6259/
6289
Connector 1
6225/6255
Connector 1
Cables
Shielded SHC68-68-EPM SHC68-68 SC68-68-EPM SHC68-68
Unshielded RC68-68 RC68-68 RC68-68 RC68-68
Accessories
Shielded
Screw
Terminal
Block
SCB-68A
SCB-68
TB-2706*
SCB-68A
SCB-68
SCB-68A
SCB-68
SCB-68A
SCB-68
BNC Terminal
Block
BNC-2110
BNC-2111
BNC-2120
BNC-2090A
BNC-2090
BNC-2115 BNC-2110
BNC-2111
BNC-2120
BNC-2090A
BNC-2090
BNC-2115
SCC SC-2345
SC-2350
SCC-68
N/A SC-2345
SC-2350
SCC-68
N/A
Unshielded
Screw
Terminal
Block
CB-68LP
CB-68LPR
TBX-68
CB-68LP
CB-68LPR
TBX-68
CB-68LP
CB-68LPR
TBX-68
CB-68LP
CB-68LPR
TBX-68
Custom Connectivity CA-1000 CA-1000 CA-1000 CA-1000
* Can only be attached directly to PXI modules front connector only, and does not require a cable.
