Appendix A Device-Specific Information
M Series User Manual A-68 ni.com
Note For more information about default NI-DAQmx counter inputs, refer to Connecting
Counter Signals in the NI-DAQmx Help or the LabVIEW Help in version 8.0 or later.
NI PCI/PCIe/PXI/PXIe-6251 Specifications
Refer to the NI 625x Specifications for more detailed information about the
NI PCI/PCIe/PXI/PXIe-6251 device.
NI PCI/PCIe/PXI/PXIe-6251 Accessory and Cabling
Options
This section describes some cable and accessory options for
M Series devices with one 68-pin connector, such as the
NI PCI/PCIe/PXI/PXIe-6251. Refer to
ni.com for other accessory
options including new devices.
Table A-14. Default NI-DAQmx Counter/Timer Pins
Counter/Timer Signal Default Pin Number (Name)
CTR 0 SRC 37 (PFI 8)
CTR 0 GATE 3 (PFI 9)
CTR 0 AUX 45 (PFI 10)
CTR 0 OUT 2 (PFI 12)
CTR 0 A 37 (PFI 8)
CTR 0 Z 3 (PFI 9)
CTR 0 B 45 (PFI 10)
CTR 1 SRC 42 (PFI 3)
CTR 1 GATE 41 (PFI 4)
CTR 1 AUX 46 (PFI 11)
CTR 1 OUT 40 (PFI 13)
CTR 1 A 42 (PFI 3)
CTR 1 Z 41 (PFI 4)
CTR 1 B 46 (PFI 11)
FREQ OUT 1 (PFI 14)
