National Instruments NI 6225 User Manual

Appendix A Device-Specific Information
M Series User Manual A-92 ni.com
NI 6255
The following sections contain information about the PCI/PXI-6255,
USB-6255 Screw Terminal, and USB-6255 Mass Termination devices.
PCI/PXI-6255
PCI/PXI-6255 Pinout
Figure A-41 shows the pinout of the PCI/PXI-6255.
For a detailed description of each signal, refer to the I/O Connector Signal
Descriptions section of Chapter 3, Connector and LED Information.
Note M Series devices may be used with most E Series accessories. However, some
E Series accessories use different terminal names. Refer to the M Series and E Series
Pinout Comparison section of Chapter 3, Connector and LED Information, for more
information.
