Appendix A Device-Specific Information
M Series User Manual A-96 ni.com
Using a BNC Accessory with Connector 1
Connector 1 of your device is compatible with BNC-2115. BNC-2115
provides BNC connectivity to 24 of the differential (48 single ended)
analog input signals on Connector 1.
You can use an SHC68-68 cable to connect to the BNC-2115.
Screw Terminal Accessories
National Instruments offers several styles of screw terminal connector
blocks such as:
• CB-68LP and CB-68LPR unshielded connector blocks
• SCC-68 I/O connector block with screw terminals, general breadboard
area, bus terminals, and four expansion slots for SCC signal
conditioning modules
• SCB-68 shielded connector block with temperature sensor (make sure
the switches are set properly)
1
• TBX-68 DIN rail-mountable connector block
• TB-2706
2
front panel mounted terminal block for PXI M Series
devices
You can use one screw terminal accessory with the signals on either
connector of your M Series device. You can use two screw terminal
accessories with one M Series device by using both connectors.
3
RTSI Cables
Use RTSI bus cables to connect timing and synchronization signals among
PCI devices, such as M Series, E Series, CAN, and other measurement,
vision, and motion devices. Since PXI devices use PXI backplane signals
for timing and synchronization, no cables are required.
Cables
The PCI/PXI-6255 has two connectors that require different cables.
1
NI recommends that you use the SHC68-68 cable when the SCB-68 is connected to Connector 1.
2
TB-2706 uses Connector 0 of your PXI device. After a TB-2706 is installed, Connector 1 cannot be used.
3
The SCC-68 only can be used with Connector 0.
