NI PXIe-1085 Modular Power Supply User Guide | © National Instruments | 3
Figure 1. Removing Power Supply
1 Power Supply Mounting Screws (8x)
2 Power Supply
3 Modular Power Supply Screws (4x)
4 NI PXIe-1085 Chassis
5 Rail Safety Catch (Both Sides)
1
5
3
2
4
