National Instruments NI PXIe-4464 User Manual

4 | ni.com | NI PXIe-4464 Calibration Procedure
Connecting the NI PXIe-4464
The NI PXIe-4464 provides connections for four channels. Figure 1 shows the front panel
connections of the NI PXIe-4464 with BNC connectors and the NI PXIe-4464 with mXLR
connectors.
Figure 1. NI PXIe-4464 BNC and mXLR Connector Front Panel
1 Top Module Mounting Screw
2PFI
3 Chassis Ground
4AI+
5AI-
6 Bottom Module Mounting Screw
NI PXIe-4464
DSA Analog Input
AI 0
AI 1
AI 2
AI 3
PFI 0
NI PXIe-4464
DSA Analog Input
AI 0
PFI 0
AI 1
AI 2
AI 3
2 2
1 1
6 6
4
3
4
5
3
3
3
5
