© National Instruments Corporation 13 NI sbRIO-961x/9612XT/963x/9632XT/964x/9642XT
Figure 10. Pinout of I/O Connector J6, 24 V Digital Input
(NI sbRIO-964x/9642XT Only)
DI0
DI2
DI4
DI6
DI8
DI10
DI12
DI14
DI16
DI18
DI20
DI22
DI24
DI26
DI28
DI30
D GND
D GND
DI3
DI5
DI9
DIa11
DI13
DI15
DI1
DI7
DI17
DI19
DI21
DI23
DI25
DI27
DI29
DI31
34 33
32 31
30 29
28 27
26 25
24 23
22 21
20 19
18 17
16 15
14 13
12 11
10 9
87
65
43
21
Pin 1
Pin 34
