© National Instruments Corporation 7 NI sbRIO-961x/9612XT/963x/9632XT/964x/9642XT
Table 1 lists and describes the connectors on NI sbRIO devices and lists the
part number and manufacturer of each connector. Refer to the manufacturer
for information about using and matching these connectors.
Table 1. NI sbRIO Connector Descriptions
Connector Description
Manufacturer and
Part Number
Recommended
Mating Connector
J3, Power 2-position MINI-COMBICON
header and plug,
0.285 in. (7.24 mm) high
Phoenix Contact,
1727566
Sauro,
CTF02BV8-BN
(included)
J1, RS-232
Serial Port
9-pin DSUB plug,
0.318 in. (8.08 mm) high,
with 4-40 jacksockets
Tyco Electronics,
5747840-6
—
P2, P3, P4,
P5, J7
50-pin polarized header plug,
0.100 × 0.100 in.
(2.54 × 2.54 mm)
3M, N2550-6002RB 3M, 8550-4500PL
*
J5 37-pin DSUB plug
with 4-40 jacksockets
FCI,
D37P24B6GV00LF
FCI, D37S24B6GV00
J6 34-pin polarized header plug,
0.100 × 0.100 in.
(2.54 × 2.54 mm)
3M, N2534-6002RB 3M, 8534-4500PL
†
*
(NI sbRIO-964x/9642XT Only) Use Samtec connector ESW-125-33-S-D if you are connecting one board to P2/P3/P4/P5/J7 and
J5 to accommodate for the height of the J5 connector.
†
(NI sbRIO-964x/9642XT Only) Use Samtec connector ESW-117-33-S-D if you are connecting one board to J6 and J5 to
accommodate for the height of the J5 connector.
