© National Instruments | 4-3
M Series User Manual
Table 4-1 shows the input ranges and resolutions supported by each M Series device family.
Analog Input Lowpass Filter
A lowpass filter attenuates signals with frequencies above the cutoff frequency while passing,
with minimal attenuation, signals below the cutoff frequency. The cutoff frequency is defined as
the frequency at which the output amplitude has decreased by 3 dB. Lowpass filters attenuate
noise and reduce aliasing of signals beyond the Nyquist frequency. For example, if the signal of
interest does not have frequency components beyond 40 kHz, then using a filter with a cutoff
frequency at 40 kHz attenuates noise beyond the cutoff that is not of interest. The cutoff
Table 4-1. M Series Input Range and Nominal Resolution
M Series Devices Input Range
Nominal Resolution Assuming
5% Over Range
NI 622x -10 V to 10 V 320 µV
-5 V to 5 V 160 µV
-1 V to 1 V 32 µV
-200 mV to 200 mV 6.4 µV
NI 625x -10 V to 10 V 320 µV
-5 V to 5 V 160 µV
-2 V to 2 V 64 µV
-1 V to 1 V 32 µV
-500 mV to 500 mV 16 µV
-200 mV to 200 mV 6.4 µV
-100 mV to 100 mV 3.2 µV
NI 628x -10 V to 10 V 80.1 µV
-5 V to 5 V 40.1 µV
-2 V to 2 V 16.0 µV
-1 V to 1 V 8.01 µV
-500 mV to 500 mV 4.01 µV
-200 mV to 200 mV 1.60 µV
-100 mV to 100 mV 0.80 µV
