National Instruments PXI-4110 User Manual

18 | ni.com | NI PXI-4110 Calibration Procedure
Table 12. NI 4110 Current Load Regulation Verification Points
Channel V Range I Range V Limit I Level Load R
1
Load R
2
Measured Current
Change
Limit (A)
Current
Change (A)
I
1
(A) V
1
(V) I
2
(A) V
2
(V)
0 6V 1A 6V 500 mA 10 Ω 4 Ω
1 20 V 20 mA 20 V 10 mA 1.8 kΩ 200 Ω
1 20 V 1A 20 V 500 mA 36 Ω 4 Ω
2 20 V 20 mA 20 V -10 mA 1.8 kΩ 200 Ω
2 20 V 1A 20 V -500 mA 36 Ω 4 Ω
