6 | ni.com | NI PXI-4130 Calibration Procedure
Verification
This section provides instructions for verifying the NI 4130 specifications.
Verification consists of generating and measuring a series of outputs using the NI 4130,
verifying the accuracy with the DMM, and comparing the results to the calibration test limits.
If the results fall within the test limits, the NI 4130 meets its published specifications, and
adjustment is optional. If the results fall outside of the test limits, you must adjust the NI 4130.
Verification tests the following NI 4130 specifications:
• Voltage programming accuracy
• Voltage measurement accuracy
• Current programming accuracy
• Current measurement accuracy
• Voltage load regulation
• Current load regulation
• Voltage line regulation
• Current line regulation
Tables 3 and 4 list configuration information for the calibration equipment required for
verification.
Table 3. Calibration Equipment Configuration for Voltage Programming and Measurement
Verification/Adjustment
NI 4130 DMM
*
Channel(s) Range Function Range
†
Input
Impedance
†
0 6V DC Voltage 10 V 10 GΩ
1 6V 10 V 10 GΩ
20 V 100 V 10 MΩ
* Use the highest resolution available on the DMM. The DMM should have a minimum of 6.5 digit
resolution.
†
Assumes an NI 4071 DMM. For all other DMMs, use the range and input impedance closest to the
values listed in this table.
