NI PXI-4130 Calibration Procedure | © National Instruments | 9
Table 5. NI 4130 Output Parameters and Test Limits for Voltage Programming
Accuracy Verification
Channel
Voltage Level
Range (V)
Iteration Output (V) Test Limit (mV)
0 6 1 0 ±4.00
2 1.5 ±4.75
3 3 ±5.50
4 4.5 ±6.25
5 6 ±7.00
1 6 1 0
±1.50
2 1.5
±2.01
3 3 ±2.52
4 4.5 ±3.03
5 6 ±3.54
6 -1.5 ±2.01
7 -3 ±2.52
8 -4.5 ±3.03
9 -6 ±3.54
20 1 0 ±1.80
2 5 ±3.50
3 10 ±5.20
4 15 ±6.90
5 20 ±8.60
6 -5 ±3.50
7 -10 ±5.20
8 -15 ±6.90
9 -20 ±8.60
