National Instruments PXIe-5841 User Manual

Maximum altitude 2,000 m (800 mbar) (at 25 °C ambient
temperature)
Pollution Degree 2
Indoor use only.
Notice Clean the hardware with a soft, nonmetallic brush or lint free cloth. Make
sure that the hardware is completely dry and free from contaminants before returning
it to service.
Note Refer to the PXIe-5841 Specifications at ni.com/manuals for complete
specifications.
Verifying the Kit Contents
Figure 1. PXIe-5841 Kit Contents
1
2
3
PXIe-5841
Vector Signal Transceiver
9 kHz – 6 GHz, 1 GHz BW
PFI 0
DIO
REF
OUT
REF
IN
RF IN
+33 dBm MAX
50
Ω
RF OUT
Reverse Power
+33 dBm MAX
ACCESS ACTIVE
LO OUT
50 Ω
LO OUT
50 Ω
LO IN
+15 dBm MAX
50 Ω
LO IN
+15 dBm MAX
50 Ω
50 Ω
50 Ω
ESD
SENSITIVE
4 5 6
1. PXIe-5841 Module
2. Screwdriver, Part Number 772006-01
3. SMA Driver Bit, Part Number 780895-01
4. PXIe-5841 Safety, Environmental, and Regulatory
Information
5. Maintain Forced-Air Cooling Note to Users
6. PXIe-5841 Getting Started Guide (This
Document)
PXIe-5841 Getting Started Guide | © National Instruments | 3
