National Instruments PXIe-5841 User Manual

Hardware Front Panel Connectors and Indicators
Figure 4. PXIe-5841 Front Panel
PXIe-5841
Vector Signal Transceiver
9 kHz – 6 GHz, 1 GHz BW
PFI 0
DIO
REF
OUT
REF
IN
ESD
SENSITIVE
RF IN
+33 dBm MAX
50 Ω
RF OUT
Reverse Power
+33 dBm MAX
50 Ω
LO OUT
50 Ω
LO OUT
50 Ω
LO IN
+15 dBm MAX
50 Ω
LO IN
+15 dBm MAX
50 Ω
50 Ω
50 Ω
Notice Apply external signals only while the PXIe-5841 is powered on. Applying
external signals while the device is powered off may cause damage.
PXIe-5841 Getting Started Guide | © National Instruments | 9

National Instruments PXIe-5841 Specifications

General

Brand	National Instruments
Model	PXIe-5841
Category	Transceiver
Language	English
