Appendix B Hardware Configuration
Table B-2. Connector Descriptions
Connector Description
AUDIO FP Audio Front Panel Header
BT1 Onboard Battery
COM1/COM2 COM Headers
DP1/DP2 DisplayPorts
FAN1 ~ FAN4 System/CPU Fan Headers
FANA, FANB I/O Fan Headers
IPMI_LAN Dedicated IPMI LAN Port
I-SATA0 ~ I-SATA3 Intel
®
PCH SATA 3.0 Ports
I-SGPIO1 Serial Link General Purpose I/O Header
J15 4-pin Connector for HDD (to provide power from the motherboard
to onboard devices)
J18 Extended CMOS Battery Connector
JD1 Speaker/Buzzer Header
JF1 Front Panel Control Header
JGPIO1 General Purpose I/O Header
JIPMB1 4-pin BMC External I2C Header
JL1 Chassis Intrusion Header
JPI2C1 Power Supply SMBbus I2C Header
JPW1 24-pin ATX Power Connector
JPW2 2V DC power for CPU (or alternative power for special enclosure
when the 24-pin ATX power is not in use)
JPWR1 4-pin 12 V Power Connector
JSD1 SATA DOM Power Connector
JSMB1 PCH SMBus Header
JSPDIF_OUT1 Sony/Phillips Digital Interface Audio Output Header
JTPM1 Trusted Platform Module/Port 80 Connector
