NI USB-9233 User Guide and Specifications 2 ni.com
Dimensions
Figure 2 shows the NI USB-9233 device dimensions.
Figure 2. NI USB-9233 Device in Millimeters (Inches)
Safety Guidelines
Operate the NI USB-9233 only as described in these operating instructions.
Note Although the NI 9233 module may have more stringent certification standards than
the NI USB-9233, when used with the USB-9162 carrier, the combined system may be
limited. Refer to the Specifications section for more details.
Hot Surface This icon denotes that the component may be hot. Touching this component
may result in bodily injury.
Caution Do not disconnect I/O-side wires or connectors unless power has been switched
off or the area is known to be nonhazardous.
Caution Do not remove modules unless power has been switched off and the area is known
to be nonhazardous.
Caution The NI USB-9233 is not certified for use in hazardous locations.
Hi-Speed USB Carrier
NI USB-9162
140.66 mm
(5.538 in.)
138.30 mm
(5.445 in.)
120.68 mm
(4.751 in.)
118.26 mm
(4.656 in.)
88.12 mm
(3.469 in.)
25.34 mm
(0.998 in.)
