Nautilus IPLE3 - Important Label Locations

Page 5
This page shows examples of the Nautilus® Leverage Strength® warning labels and communication stickers placed on the equipment
as part of the manufacturing process. It is critical that owners maintain the integrity and placement of these stickers. If you nd any
stickers missing or damaged each sample indicated includes its corresponding part number so that replacements may be ordered.
NOTE: STICKERS AND LABELS ARE NOT SHOWN TO SCALE
Bolt Down Label
Instruction Placard
Pinch Point
Serial Label
Bolt Down Label
Instruction Placard
Pinch Point
Serial Label
IMPORTANT LABEL LOCATIONS
731-0512
LEG EXTENSION
LEG EXTENSION
731-7069-USA
®
CAUTION
PRUDENCE
VORSICHT
THIS MACHINE IS EQUIPPED WITH LOCK N LOAD
®
TECHNOLOGY.
FOR WEIGHT SELECTION, SWITCH DESIRED PLATE TO THE
ON
POSITION. ALL OTHER PLATE SHOULD BE IN THE
OFF POSITION.
QUADRICEPS
PRIMARY
READ ALL SAFETY WARNINGS PRIOR TO USE
GRASP THE RED ADJUSTMENT HANDLE BEHIND BACK
PAD AND SET SEAT AND BACKREST TO ALIGN KNEES
WITH AXIS POINT
ADJUST LOWER ROLLER PAD TO A COMFORTABLE
POSITION IN FRONT JUST ABOVE THE ANKLE BY
PULLING THE HANDLE LOCATED NEXT TO THE SEAT
SET DESIRED PRE STRETCH RANGE OF MOTION BY
PULLING THE HANDLE LOCATED ABOVE THE CAM
AND SETTING THE DESIRED START POSITION
TO INITIATE MOTION, EXTEND THE KNEES IN A
SLOW CONTROLLED MOTION
= PMS 355 C
= PMS 152 C
= PMS
HEXACHROME
BLACK C
= PMS 1805 C
731-7069-USA
731-0517
