48 | Connect Northstar 6000i / 6100i
Key for above two drawings
A AA010024NOR 2 kW scanner comes with 15 m (49 ft) cable attached. Cable from Scanner
connects to Radar Processor box. An optional longer cable is available but only up
to 20 m (65.5 ft).
B AA010089
Optional 20 m (65.5 ft) scanner cable. Will require disassembly of dome to
connect this replacement cable. Cable has radar processor connector on one end,
and three small terminated flat connectors on the other.
CAUTION: This cable should only be installed by an experienced radar service
technician!
C AA010012 2 kW radar processor box. No cables supplied. Connects to 6x00i system via
RS422.
The radar box requires heading @ 10 Hz. For vessels with SimNet heading, use
an AT10HD (see D) SimNet NMEA 0103 converter. Ethernet cables need to
ordered (see E).
2 kW system is 12 V DC ONLY 25 W max. Power connects to the two screw
terminals.
D NS003107 Radar and communications cable 3 m (9.6 ft) included with 6x00i.
D1 Radar Connection cable 0.5 m (1.6 ft) 12 pin female. Connects to the radar
processor port labeled NMEA / COMMS or can be extended using optional
NS003108 (E).
D2 Smartcraft Gateway interface (optional) 0.5 m (1.6 ft) 8 pin male.
D3 NMEA / RS232 / Remote power on cable 0.5 m (1.6 ft) terminating in bare wires.
All unused wires must be isolated from each other.
E NS003108 Radar and communications extension cable 3 m (9.6 ft).
F
RC37 heading sensor or third party NMEA 0183 heading sensor which can output
heading at greater than 10 Hz.
G
Junction box (not supplied).
H
Power on option 1
I
Power on option 2
J
NS6000i / 6100i display head (master display on a multi-display system).
K Relay Power on option 3 used when 6x00i and radar processor have isolated power
supplies or are located more than 5 m (16.5 ft) apart.
