4. Principal Components of the controller MCL 5.10
The main controller components are listed below:
a) Comunication interfaces - RS232 or USB (for parametrization),CL and RS485 for data collection
from meters
b) Internal 450mAh Li-polymer battery to ensure the notification of power failure or data transfer
function support.
c) CSD/GSM/GPRS/3G modem is used for modem programming, firmware update, data reading and
parameterization
GSM/GPRS Modem
GSM/GPRS bands
850/900/1800/1900 Mhz
Class of power transmission
Multi-slot class 8, CS1-CS4, Class B
Data Speed
up to 85.6 kb/s
Uplink time slot
2
Antenna Connector type
SMA (50 Ohm)
3G modem
UMTS / EDGE Bands
850/900/1800/1900/2100 Mhz
Class of power transmission
Multi-slot class 12, MCS1-9, Class B
Data Speed
HSUPA cat 6, up to 5.76 Mb/s UL
HSDPA cat 8, up to 7.2 Mb/s DL
WCDMA PS up to 384 kb/s DL/UL
EDGE multi-slot class 12, up to 236.8 kb/s DL/UL
Table 3-1. Main characteristics of a GSM/GPRS modem module
5. Technical Characteristics
Power supply input voltage range (50/60Hz)
90 V 264 V AC
Power consumption:
a. maximum in transmission mode:
b. average in duty mode:
< 10 VA
< 5 VA
Internal backup power supply
450mAh LiPo battery,
mounted without
soldering
Internal battery complete loading time
3 hours
PC to controller net baud rate via RS232 device interface, 8N1
bits, Baud
19200
PC to controller net baud rate via USB device interface, 8N1
bits, Baud
115200
Number of meters connected to RS485 interface
1 32
Number of meters connected to CL interface
1 3
Number of simultaneous communication sessions GSM/CSD/GPRS/3G
6
Work temperature range,
о
С
-20 ... +55
Storage temperature range,
о
С
-40 ... +70
Relative humidity, % without condensate
20 ... 75
Dimensions, mm
93 x 68 x 37
Plastic Materials, safety of flammability
ABS
Immunity to surge pulse
7 kV (1,2/50 µs)
RoHS
Compliant
Antenna
SMA
Protection degree based on IEC60529
IP51 under the cover of
the meter
Table 4-1. MCL 5.10 controller technical characteristics
Table 4-2 MCL 5.10 controller indicators description
Operation and received signal strength indication RGB LED1:
- Not registered to GSM network / no SIM card
- Registered to GSM/GPRS network;
R long pulse (0,4 Hz /1s)
G pulse
