Page #44 background imageLoading...
Page #44 background image
44
Planar-D1 / Compact-M2 R7
Technical data
Technical information
Receive frequency range 434.050 – 434.750 MHz
Frequency management yes
Typical response time of the
control commands
approx. 50 ms
Active/passive 2 s
Safety level Emergency stop output: PL d
Emergency stop: Fuse protection T4A 250 V fine-wire fuse 8.5 x 8.5 mm (Schurter MST250)
Max. current load max. 4 A
Power supply
12 VDC | 24 VDC | 8 36 VDC
48 VAC | 110 VAC | 230 VAC (± 10 %)
Max. power consumption
(average, depending on the output unit)
12.0 VDC: < 4.0 + 1.5 + 0.8*7 VA
24.0 VDC: < 3.0 + 1.5 + 0.8*7 VA
Protection class IP65
Data security
Addressing of each receiver (transmitter)
by unique bit coding
Ambient operating temperature -20 °C to +70 °C
Weight (without antenna) approx. 800 g
Measurements (L x W x H) 174 mm x 89 mm x 65 mm
Receiver Compact-M2 R7
