NBE RTB 10 - Electrical Connections

Ready To Burn
Ready To Burn: Version 1.0 October 2015 Page 13 of 24
Electrical connections
IN
OUT
230
PE-N-L
230Volt AC
SAFETY THERMOSTAT
L-L
Safety thermostat cutoff
MOTOR
PE-N-L1
External auger
BURNER
PE-N-L2
Fan
BURNER
PE-N-L3
Internal auger
BURNER
PE-N-L4
Ignition
EKSTRA 1
PE-N-L5
Circulation pump can be set to other equipment.
EKSTRA 1
PE-N-L6
Compressor cleaning can be set to other equipment.
EKSTRA 2
PE-N-L7
Deashing Auger.
EKSTRA 2
PE-N-L8
Optional output for equipment.
EKSTRA 3
PE-N-L9
Boiler Compressor Valve 1
EKSTRA 3
PE-N-L10
Boiler Compressor Valve 2
BUS
GRD, TX, RX,
Expansion module
ILT
V1, V, V2
O2 controller
KONTAKT
K-K1
External ON/OFF
KONTAKT
K-K2
Free
PULS
P-P1
Flow meter system
PULS
P-P2
Flow meter solar heating
PULS
P-P3
Free
PULS
P-P4
Fan RPM
AFSTAND
-, SIG, +
Distance sensor for hopper
LAN
RJ45
Internet connection
TEMP.
T- T1
Boiler temperature
TEMP.
T – T2
Smoke temperature
TEMP.
T – T3
Boiler return temperature
TEMP.
T – T4
DHW temperature
TEMP.
T – T5
External temperature
TEMP.
T – T6
Free
TEMP.
T – T7
Free
EKS / FOTO
T – T9
Temperature sensor burner
EKS / FOTO
T-T10
Photo sensor burner
IN
OUT
