NCE NCE897DVD - I N S Ta L L at I O N S T E P S

PL AS TIC TR IM
SER VIC E K EYS
O P E N b u tto n
CRA DLE
UNI T
1
1. Remove the unit from the cradle as follows.
a. Remove the plastic trim.
b. Insert service keys and then slide the cradle off as illustrated below.
2. Complete all wiring as per instructions on page 2.
3. Remove the control panel from the unit as follows.
a. Press the release button (18) to open the control panel.
b. Hold the right end of the control panel and pull to the right a little
then remove it.
INSTALLATION STEPS
