NOTE:
(1)The above electrical wiring diagrams are only for your reference, please subject the heat
pump to the posted wiring diagram.
(2)The swimming pool heat pump must be earthed well, although the unit heat exchanger is
electrically isolated from the rest of the unit .Earthing the unit is still required to protect you
against short circuits inside the unit .Bonding is also required.
Disconnect: A disconnect (circuit breaker, fused or un-fused switch) should be located within
sight of and easily accessible from the unit. This is common practice on commercial and
residential heat pumps. It prevents remotely-energizing unattended equipment and permits
turning off power to the unit while the unit is being serviced.
6. Display Controller Operation
LED Display Controller
6.1 Overview
◎ The controller is specially designed for the swimming pool heat pump series, with
features as below:
⚫ Heating and cooling mode;
⚫ Could show and change the running and setting parameters of the system, easy for
user to install and test.
⚫ With automatic protection and fault warning function.
⚫ With strong system protection function, like compressor delay protection, high
pressure, low pressure, sensor protection, water flow detects etc.
⚫ The communication distance between the heat pump unit and remote controller
shouldn’t be less than 100 meters. Communication port is 485.
⚫ Strong anti-interference, stable performance.
6.2 Basic Model of System Control Chart
◎ System Chart
◎ Control Principle
⚫ The Outdoor unit is run according to the remote controller’s order
⚫ The remote controller could change the running parameters and send the running
parameters to the outdoor unit
⚫ The outdoor unit could detect the running condition and send the info or fault to the
remote controller
