NDE Pool MASTER PLUS NDE-08-DCP - Specifications

- 5 -
1. Specifications
1.1 Technical data
Product model
NDE-08-DCP
NDE-10-DCP
NDE-11-DCP
NDE-14-DCP
Advised pool volume
（
m3
）
(with cover)
15~30
20~40
25~50
30~60
Operating ambient temperature range
（℃）
-7 ~43
Parameters
heating*
Heating capacity
(kW)
7.50~1.92
9.50~2.10
11.00~2.50
14.00~3.15
Heating capacity (BTU/h)
25500~6528
32300~7140
37400~8500
47600~10710
Input power (kW)
1.15~0.13
1.46~0.14
1.83~0.17
2.15~0.21
COP
6.5~14.8
6.5~15.0
6.0~14.7
6.5~15.0
COP at 50% capacity
10.50
11.00
11.00
10.50
heating**
Heating capacity
(kW)
5.80~1.42
7.2~1.50
8.5~1.65
10.7~2.40
Heating capacity (BTU/h)
19720~4828
24480~5100
28900~5610
36380~8160
Input power (kW)
1.15~0.20
1.43~0.21
1.77~0.23
2.12~0.34
COP
5.0~7.1
5.0~7.2
4.8~7.2
5.0~7.1
COP at 50% capacity
6.50
6.50
6.50
6.50
Rated current(A)
5.1~0.9
6.3~0.9
7.8~1.0
9.3~1.5
Minimum fuse current (A)
10
12
15
20
Advised water flux
（
m³/H
）
2~4
2~4
3~5
4~6
IP Grade (Level of protection)
IPX4
IPX4
IPX4
IPX4
Anti-electric shock Rate
I
I
I
I
Nosie
Noise (dB(A)) (1m)
38~48
38~48
40~50
42~51
Sound pressure of 50%
capacity at 1m dB(A)
40
40
41
43
Sound pressure at 10m dB(A)
18~25
18~25
19~26
22~27
Net weight/Gross weight(kg)
62/70
62/70
64/72
77/87
Diameter of pipe (mm)
φ50
Standard Configuration
Metal plate
ABS plastic casing black color
Body size(W*D*H)mm
1000X396X640
Compressor
Panasonic
Refrigerant consumption
（
g
）
R32/350g
R32/380g
R32/450g
R32/550g
Power supply
220V/1p/ 50Hz/60HZ
Condenser
Titanium in PVC
Controller
Single System
（
CHICO
）
Power line connect with unit
3*1.5mm2
3*1.5mm2
3*2.5mm2
3*2.5mm2
Remark:heating*: working condition, Inlet water temperature 26
℃
, Outlet water temperature 28
℃
, Dry bulb temperature
27
℃
.Humidity 80%.
heating**: working condition, Inlet water temperature 26
℃
, Outlet water temperature 28
℃
, Dry bulb temperature
15
℃
.Humidity 70%.
