NDE Pool MASTER PLUS NDE-08-DCP - Product Model

- 6 -
Product model
NDE-17-DCP
NDE-20-DCP
NDE-24-DCP
Advised pool volume
（
m3
）
(with cover)
40~75
55~100
60~110
Operating ambient temperature range
（℃）
-7 ~43
Parameters
heating*
Heating capacity (kW)
17.00~3.75
20.00~4.00
24.00~4.80
Heating capacity (BTU/h)
57800~13090
68000~13600
81600~16320
Input power (kW)
2.62~0.25
3.33~0.27
4.00~0.32
COP
6.5~15.0
6.0~14.8
6.0~15.0
COP at 50% capacity
11.00
11.00
11.00
heating**
Heating capacity (kW)
13.0~2.65
15.6~2.85
18.7~3.42
Heating capacity (BTU/h)
44200~9010
53040~9690
63580~11630
Input power (kW)
5.0~7.4
3.25~0.40
3.89~0.49
COP
4.56-7.19
4.8~7.0
4.8~7.0
COP at 50% capacity
6.50
6.50
6.50
Rated current(A)
11.3~1.6
14.3~1.8
17.8~2.3
Minimum fuse current (A)
22
30
35
Advised water flux
（
m³/H
）
6~9
8~10
9~12
IP Grade (Level of protection)
IPX4
IPX4
IPX4
Anti-electric shock Rate
I
I
I
Noice
Noise (dB(A)) (1m)
43~52
43~53
44~54
Sound pressure of 50%
capacity at 1m dB(A)
44
44
45
Sound pressure at 10m dB(A)
23~30
24~31
25~32
Net weight/Gross weight(kg)
81/91
81/91
90/100
Diameter of pipe (mm)
φ50
Standard Configuration
Metel plate
ABS plastic casing black color
Body size (W*D*H) mm
1125X416X765
Compressor
Panasonic
Refrigerant consumption
（
g
）
R32/750g
R32/800g
R32/850g
Power supply
220V/1p/ 50Hz/60HZ
Condenser
Titanium in PVC
Controller
Single System
（
CHICO
）
Power line connect with unit
3*4.0mm
2
3*6.0mm
2
3*6.0mm
2
Remark:heating*: working condition, Inlet water temperature 26
℃
, Outlet water temperature 28
℃
, Dry bulb temperature
26
℃
.Humidity 80%.
heating**: working condition, Inlet water temperature 26
℃
, Outlet water temperature 28
℃
, Dry bulb temperature
15
℃
.Humidity 70%.
* Above data are subjects to modification without notice.
