6. TEMPRA BATTERIES
PARALLEL
You can connect up to 4 TEMPRA Lithium Batteries in
parallel, series connection is not allowed.
Follow the instructions for correct installation:
1. Select Master mode on one of the batteries and set
the other Tempra to Slave. Act on Dip Switch No. 4
(Chapter 10).
2. Make the electrical connection in parallel.
3. Create the N-BUS network - connect the data cable
forming a chain from one battery to the next
(connect any other NDS N-BUS devices present).
NOTE
• The connection cable between several N-BUS devices is a 6-
pole (straight through) cable with RJ11 6C/6P connectors at
both ends. It is possible to buy a pre-assembled NDS cable
available in different models and lengths BC 03M (3m), BC
06M (6m) and BC 10M (10m).
• The N-BUS cable for DTB01 display is a proprietary NDS cable,
and it is different from BC 03M, BC 06M and BC 10M.
