English-8
Controls
OSD (On-Screen Display) Control Functions
1. Basic functions of the touch keys on the front of the monitor
OSD Menu
INPUT/RESET SELECT
– +
Not displaying on screen
Selects input signal. Displays OSD. Shortcut to Brightness. Shortcut to Contrast.
Displaying on screen
Icon Select
Displays OSD menu and
selects function icon.
Moves leftward. Moves rightward.
Function Adjustment
Reset the function. Adjusts the function of the
selected icon.
Adjusts down. Adjusts up.
NOTE: You can directly change to LOW BLUE LIGHT MODE by touching the SELECT key for 3 seconds or more.
2. OSD structure
Example:
Main Menu (Icon Select)
Sub Menu (Icon Select)
Touch
“SELECT”
key
Touch
“SELECT”
key again
Touch “–” or
“+” to select
an icon
Main Menu (Adjust)
Sub Menu (Adjust)
Touch “SELECT” key
Touch
“SELECT” key
Adjust by using
“–” or “+”
Select by using
“–” or “+”
Touch
“–” or “+”
Example: TOOL sub menu
Touch “SELECT” key
Touch
“SELECT” key
To Next Page
