NEC AccuSync LCD72VM User Manual

8-4
Replacement Parts List of Main Board
CBPC780KQLNV (MAIN BOARD)
Symbol
For U.S./Europe
(TPV Part Number)
Description
C122 67L215Y2207NV 105°C 22UF +-20% 50V
C129 67L215Y2207NV 105°C 22UF +-20% 50V
C136 67L215Y2207NV 105°C 22UF +-20% 50V
C140 67L215Y2207NV 105°C 22UF +-20% 50V
C143 67L215Y100 7N LOW ESREC 10UF 50V NCC
C158 67L215Y100 7N LOW ESREC 10UF 50V NCC
C161 67L215V221 4N LOW ESR EC 220UF 25V NC
C162 67L215V221 4N LOW ESR EC 220UF 25V NC
C165 67L215V470 4N LOW ESR EC 47UF 25V NCC
C166 67L215V470 4N LOW ESR EC 47UF 25V NCC
C169 67L215Y100 7N LOW ESREC 10UF 50V NCC
C170 67L215V470 4N LOW ESR EC 47UF 25V NCC
C171 67L215V470 4N LOW ESR EC 47UF 25V NCC
C172 67L215Y100 7N LOW ESREC 10UF 50V NCC
C182 67L215V470 4N LOW ESR EC 47UF 25V NCC
CN201 33L8027 12 WAFER 2*6P 2.0MM R/A
CN301 88L 35315F H D-SUB 15PIN
CN501 33L3802 2 WAFER EH-2
CN503 33L802724B H PIN HEADER 24P 2.0mm
CN601 33L801714A H PIN HEADER 2*7 R/A
CN602 33L8027 16 WAFER 16PIN 2.0mm DIP
U101 56L1125522QM3 SM 5964C40J
X101 93L 22 53 CRYSTAL 14.318MHzHC-49U
X102 93L 22 53 CRYSTAL 14.318MHzHC-49U
C102 65L0603560 31 CHIP 56PF 50V NPO
C103 65L0603560 31 CHIP 56PF 50V NPO
C104 65L0603473 32 CHIP 0.047UF 50V X7R
C106 65L0603473 32 CHIP 0.047UF 50V X7R
C108 65L0603473 32 CHIP 0.047UF 50V X7R
C112 65L0603473 32 CHIP 0.047UF 50V X7R
C113 65L0603473 32 CHIP 0.047UF 50V X7R
C114 65L0603473 32 CHIP 0.047UF 50V X7R
C115 65L0603104 12 0.1UF +-10% 16V X7R
C116 65L0603104 12 0.1UF +-10% 16V X7R
C117 65L0603330 31 33PF+-5% 50V NPO
C118 65L0603221 31 CAP:CER 220PF 5% 50V SM
