2.6 Check Power Manage Function
Monitor should enter to power saving mode if the following condition occurs.
Mode Horizontal Vertical Power Supply Input Timing Power Consumption
On ON ON 240Vac VESA 1024X768 (75Hz) 34W
Stand-by OFF ON 240Vac VESA 1024X768 (75Hz) 2W
Suspend ON OFF 240Vac VESA 1024X768 (75Hz) 2W
Off OFF OFF 240Vac VESA 1024X768 (75Hz) 2W
3. External Inspection on the LCD Module
3.1 For QDI Panel (QDI 17EL0707 Rev.02)
External Inspection
Inspection item Criteria Reject count (N)
D > 0.5mm N = 0
0.5mm ≥ D ≥ 0.15mm N ≤ 3
D < 0.15mm Don’t care
Black spot, White spot,
Foreign circular
Material Dent &bubble
Minimum distance between defects: 10mm
L > 4.0mm; W > 0.1mm
N ≤ 0
4mm ≥ L ≥ 2.0mm, 0.1mm ≥ W ≥ 0.01mm N ≤ 3
Scratches, lint
L: length; W: width (mm)
L < 2.0mm, W< 0.01mm Don’t care
The external visual inspection: The inspection shall be conducted by using a single 20W fluorescent lamp for
illumination and the distance between the MODULE and the eyes of the inspector shall be 35 cm or more.
* The area for external inspection is active area plus 1.0mm width. (Upper, Lower, Left and Right)
L
W
L = Lon
To Next Page
