- 17 -
6. NO DEGAUSSING
CHECK
IC401 PIN 6
(5V)?
CHECK
Q920 COLLECTOR
VOLTAGE
(0.5V)?
CHECK
P901?
CHECK
RL901?
TROUBLE IN
IC401 (MICOM)
TROUBLE IN
D925
TROUBLE IN
P901
TROUBLE IN
RL901
TROUBLE IN
TH901,
DEGAUSSING COIL
NO DEGAUSSING
NO
NO
NO
NO
YES
YES
YES
YES
