10
Alignment Instruction
7-6. The adjustment of PINCUSHION
7-6-1. Receive PAL CROSSHATCH pattern(signal of company:PAL-B 5CH).
7-6-2. Press the PR up/down Keys ( / ) to select PARAVOLRA.
Referring to the 2th line of both side, adjust with Vol Up/Down ( / ) keys.
7-6-3. The other adjustment list of Pincushion
- ADJUSTMENT LIST : EW TRAPEZ, CORNER, H-BOW, H-PARALELL
- Fix adjustments of related Pincution(except EW PARA.) after EEPROM
presetting, but those can be adjusted in case of need.
