NEC DSC-3261HA - Part List

21
LOC PART CODE PART NAME PART DESCRIPTION REMARKLOC PART CODE PART NAME PART DESCRIPTION REMARK
Part List
U102B 4859003750 PLUG PHONE AS PLUG+CABLE 1365AWG26=150B
X501 5XE20R250E CRYSTAL QUARTZ HC-49/U 20.2500MHZ 30PPM
X601 5XE18R432E CRYSTAL QUARTZ HC-49/U 18.43200MHZ 30PPM
ZZ200 PTMPJ0D713 PCB MAIN (RHU) AS DSC-3261HA
C504 CEXF1C471V C ELECTRO 16V RSS 470MF (8X12)TP
C549 CEXF1C471V C ELECTRO 16V RSS 470MF (8X12)TP
C593 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20) TP
C604 CEXF1E102V C ELECTRO 25V RSS 1000MF (13X20) TP
C716 CEXF1C222V C ELECTRO 16V RSS 2200MF (16X31.5) TP
ZZ200 PTMPJBD713 PCB MAIN M-10 AS DSC-3261HA
10 2TM18006BE TAPE MASKING 6.2X500
P502 485923202S CONN WAFER YW025-07 (STICK)
P504 485923522S CONN WAFER YW025-09 (STICK)
P507 485923192S CONN WAFER YW025-06 (STICK)
P508 485923172S CONN WAFER YW025-04 (STICK)
P601 485923172S CONN WAFER YW025-04 (STICK)
P604 485923162S CONN WAFER YW025-03 (STICK)
P701 485923202S CONN WAFER YW025-07 (STICK)
P702 485923202S CONN WAFER YW025-07 (STICK)
P704 485923162S CONN WAFER YW025-03 (STICK)
PA05 485923522S CONN WAFER YW025-09 (STICK)
ZZ200 PTMPJRD713 PCB MAIN RADIAL AS DSC-3261HA
C201 CEXF1H220V C ELECTRO 50V RSS 22MF (5X11) TP
C204 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C205 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C207 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C210 CEXF1H220V C ELECTRO 50V RSS 22MF (5X11) TP
C211 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C212 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C501 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C502 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C505 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C507 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C508 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C511 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C519 CMXM2A224J C MYLAR 100V 0.22MF J
C520 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C521 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C522 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C525 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C534 CMXM2A683J C MYLAR 100V 0.068MF J (TP)
C535 CMXM2A683J C MYLAR 100V 0.068MF J (TP)
C536 CMXM2A683J C MYLAR 100V 0.068MF J (TP)
C546 CEXF1H339V C ELECTRO 50V RSS 3.3MF (5X11) TP
C550 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C551 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C553 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C560 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C561 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C562 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C563 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C564 CEXF1C331V C ELECTRO 16V RSS 330MF (8X11.5) TP
C565 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C566 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C573 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C575 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.5) TP
C590 CXCH1H309C C CERA 50V CH 3PF C
C591 CXCH1H309C C CERA 50V CH 3PF C
C592 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C605 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C608 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C610 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C611 CEXF1H339V C ELECTRO 50V RSS 3.3MF (5X11) TP
C612 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C613 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C614 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C615 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C616 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C620 CXCH1H509D C CERA 50V CH 5PF D (TAPPING)
C621 CXCH1H509D C CERA 50V CH 5PF D (TAPPING)
C623 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C624 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C626 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C630 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C634 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C650 CEXF1E221V C ELECTRO 25V RSS 220MF (8X11.5) TP
C651 CMXM2A222J C MYLAR 100V 2200PF J (TP)
C660 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C661 CMXM2A224J C MYLAR 100V 0.22MF J
C662 CMXM2A224J C MYLAR 100V 0.22MF J
C665 CMXM2A222J C MYLAR 100V 2200PF J (TP)
C667 CMXM2A222J C MYLAR 100V 2200PF J (TP)
C668 CMXM2A224J C MYLAR 100V 0.22MF J
C669 CMXM2A224J C MYLAR 100V 0.22MF J
C671 CMXM2A103J C MYLAR 100V 0.01MF J (TP)
C672 CMXM2A103J C MYLAR 100V 0.01MF J (TP)
C673 CMXM2A103J C MYLAR 100V 0.01MF J (TP)
C674 CMXM2A103J C MYLAR 100V 0.01MF J (TP)
C715 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C718 CCXB1H103K C CERA 50V B 0.01MF K
C731 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
C734 CMXL2E474J C MYLAR MEU 250V 0.47MF J
C735 CMXL2E474J C MYLAR MEU 250V 0.47MF J
C736 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
