22
LOC PART CODE PART NAME PART DESCRIPTION REMARKLOC PART CODE PART NAME PART DESCRIPTION REMARK
Part List
C737 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C738 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
CA01 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
CA02 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
CA03 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
CA39 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
CA40 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
CA41 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
CA50 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
CA51 CEXF1H220V C ELECTRO 50V RSS 22MF (5X11) TP
D202 DUZP33B—- DIODE ZENER UZP 33B
D203 DUZP33B—- DIODE ZENER UZP 33B
I604 1K1A7042AP IC REGULATOR KIA7042AP
I706 1K1A7025AP IC RESET KIA7025AP
Q202 TKTC3198Y- TR KTC3198Y
Q501 TKTC3198Y- TR KTC3198Y
Q542 TKTA1266Y- TR KTA1266Y (TP)
Q543 TKTA1266Y- TR KTA1266Y (TP)
Q544 TKTA1266Y- TR KTA1266Y (TP)
Q550 TKTC3198Y- TR KTC3198Y
Q590 TKTC3198Y- TR KTC3198Y
Q591 TKTC3198Y- TR KTC3198Y
Q599 TKTA1266Y- TR KTA1266Y (TP)
Q608 TKTA1266Y- TR KTA1266Y (TP)
Q701 TKTC3198Y- TR KTC3198Y
Q702 TKTA1266Y- TR KTA1266Y (TP)
Q741 TKTC3198Y- TR KTC3198Y
QA01 TKTC3198Y- TR KTC3198Y
QA02 TKTC3198Y- TR KTC3198Y
QA03 TKTC3198Y- TR KTC3198Y
QA04 TKTC3198Y- TR KTC3198Y
QA05 TKTC3198Y- TR KTC3198Y
QA10 TKTC3198Y- TR KTC3198Y
QA11 TKTC3198Y- TR KTC3198Y
QA22 TKTC3198Y- TR KTC3198Y
ZZ200 PTMPJAD713 PCB MAIN AXIAL AS DSC-3261HA
10 2TM14006LB TAPE MASKING 3M #232 6.0X2000M
20 2TM10006LB TAPE MASKING 3M #232-MAP-C 6.2X2000M
A001 4859815492 PCB MAIN 330X246 DIB
C202 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C203 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C208 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C209 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C503 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C506 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C509 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C510 CCZF1H473Z C CERA 50V F 0.047MF Z
C512 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C513 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
C514 CCZB1H221K C CERA 50V B 220PF K (AXIAL)
C515 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C516 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C526 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C528 CCZF1H223Z C CERA 50V F 0.022MF Z
C529 CCZF1H223Z C CERA 50V F 0.022MF Z
C530 CCZF1H223Z C CERA 50V F 0.022MF Z
C545 CCZF1H103Z C CERA 50V F 0.01MF Z
C547 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C548 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C554 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C567 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
C568 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C569 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
C570 CCZB1H151K C CERA 50V B 150PF K (AXIAL)
C578 CZCH1H471J C CERA CH 50V 470PF J AXIAL 52MM
C579 CZCH1H471J C CERA CH 50V 470PF J AXIAL 52MM
C580 CCXB1H471K C CERA 50V B 470PF K (TAPPING)
C582 CCXB1H471K C CERA 50V B 470PF K (TAPPING)
C583 CCZF1H103Z C CERA 50V F 0.01MF Z
C584 CCXB1H471K C CERA 50V B 470PF K (TAPPING)
C586 CCXB1H471K C CERA 50V B 470PF K (TAPPING)
C587 CCZB1H221K C CERA 50V B 220PF K (AXIAL)
C589 CZCH1H471J C CERA CH 50V 470PF J AXIAL 52MM
C594 CCZB1H561K C CERA 50V B 560PF K
C601 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C603 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C617 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C622 CCZF1H103Z C CERA 50V F 0.01MF Z
C629 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C631 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C635 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C639 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C640 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C641 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C642 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C666 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C690 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C732 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
CA20 CCXB1H471K C CERA 50V B 470PF K (TAPPING)
CA21 CCXB1H471K C CERA 50V B 470PF K (TAPPING)
CA22 CCXB1H471K C CERA 50V B 470PF K (TAPPING)
CA23 CCXB1H471K C CERA 50V B 470PF K (TAPPING)
D506 D1N4148—- DIODE 1N4148 (TAPPING)
D540 DUZ7R5BM— DIODE ZENER UZ-7.5BM
