NEC DSC-3261HA - CM-921 F EEPROM Presetting DATA

1. Pre-setted Chanel for Australian
3
2. CM-921F EEPROM Presetting DATA
2 PAL 2CH ( 64.25MHz) for Austlaina Field Chanel
7 PAL 7CH (182.25MHz) for Austlaina Field Chanel
9 PAL 9CH (196.25MHz) for Austlaina Field Chanel
10 PAL 10CH (209.25MHz) for Austlaina Field Chanel
28 PAL 28CH (527.25MHz) for Austlaina Field Chanel
PR.
No.
2. Pre-setted Chanel for Mass-production
30
PAL-B 10CH (623.25MHz)
For white balance
31
PAL-B 2CH ( 48.25MHz)
For Geometry & Nicam stereo check
32
PAL-B 5CH (175.25MHz)
For Geometry & 2-carrier dual check
33
PAL-B 10CH (210.25MHz)
For fuction check
34
PAL-B 4CH ( 62.25MHz)
For fuction check
35
SCM-B 12CH (224.25MHz)
For fuction check
36
PAL-K 18CH (511.25MHz)
For fuction check
37
PAL-I 31CH (551.25MHz)
For fuction check
38
PAL-B 8CH (196.25MHz)
For purity & 2-carrier stereo
39
NTSC 3CH ( 61.25MHz)
For NTSC
40
NTSC 8CH (181.25MHz)
For NTSC Geomery
41
PAL-G 21CH (471.25MHz)
reserved
* presetted channel for mass-production can be changed.
White/Black
RETMA
CROSS HATCH
COLOR BAR
PHILIPS
RETMA
COLOR BAR
RED
PR.
No.
COLOR BAR
RETMA
R,B,W
DEM
400Hz 60% MOD. NICAM St. (L :1KHz, R :0KHz)
1KHz 60% MOD. 2-C Dual (Main:1KHz, Sub:5KHz)
400Hz 60% MOD.
1KHz 80% MOD. NICAM Dual(Main:1KHz, Sub:3KHz)
SWEEP 60%(Standard:1KHz, 268Hz~4.2KHz)
SWEEP 60%(Standard:1KHz, 268Hz~4.2KHz)
400Hz 60% MOD. NICAM St. (L :1KHz, R :0KHz)
5KHz 60% MOD. 2-C St. (L :0KHz, R :5KHz)
1KHz Korean Dual(1KHz,5KHz)
SWEEP (268Hz~4.2KHz)
1KHz 60% MOD.
-
3. Pre-setted DATA for Adjusments
PAL NTSC
S1
-
S2
-
Screen adjustments
S3
-
S4
-
S5
-
V-CENTER +3095 +3927
V-SIZE +151 +138
H-CENTER +86 +87
H-SIZE +1430 +1156
PARABOLA -74 -170
EW TRAPEZ +16 -19
CORNER
H BOW +83 +37
H PARALL
V LINEAR -03 -05
TILT
P H POS
P V POS
P R/G/B Peak
P CONT
P BRIGHT
R/G/B DRIVE
R/G/B BIAS
SUB BRI.
SUB CONT.
BRM
AGC MAIN
AGC SUB
S11
-
S12
-
CONT
For Changing SUB-Brightness Adjust Reference
IBRM
For Changing Screen Adjust Reference
-
-
-
-
-
-
-
Not Use
Shipping
SVC Main Menu
S10
AGC
S6
Geometry
S7
PIP
DSC-3261HA
S9
SUB PICTURE
Screen
Sound Test
Picture Test
Heat-Run
Timer LED test
+40
-18
07
S CORRECT
+7
0
170/170/170
40/40/40
30
8
160/160/160
7
13
13
S8
WHITE
BALANCE
17
07
127
50
340
remarkKEY
Name Details
