NEC DSC-3261HA - Page 36

35
LOC PART CODE PART NAME PART DESCRIPTION REMARKLOC PART CODE PART NAME PART DESCRIPTION REMARK
R902 RD-AZ912J- R CARBON FILM 1/6 9.1K OHM J
R904 RD-AZ393J- R CARBON FILM 1/6 39K OHM J
R906 RD-AZ392J- R CARBON FILM 1/6 3.9K OHM J
R907 RD-AZ912J- R CARBON FILM 1/6 9.1K OHM J
R909 RD-AZ471J- R CARBON FILM 1/6 470 OHM J
R911 RD-2Z471J- R CARBON FILM 1/2 470 OHM J
R912 RD-AZ912J- R CARBON FILM 1/6 9.1K OHM J
R914 RD-AZ333J- R CARBON FILM 1/6 33K OHM J
R916 RD-AZ820J- R CARBON FILM 1/6 82 OHM J
R917 RD-AZ152J- R CARBON FILM 1/6 1.5K OHM J
R918 RD-AZ122J- R CARBON FILM 1/6 1.2K OHM J
R919 RD-AZ683J- R CARBON FILM 1/6 68K OHM J
R922 RD-4Z620J- R CARBON FILM 1/4 62 OHM J
R924 RD-AZ100J- R CARBON FILM 1/6 10 OHM J
R925 RD-AZ820J- R CARBON FILM 1/6 82 OHM J
R926 RD-AZ683J- R CARBON FILM 1/6 68K OHM J
R927 RD-2Z331J- R CARBON FILM 1/2 330 OHM J
R928 RD-AZ152J- R CARBON FILM 1/6 1.5K OHM J
R929 RD-AZ122J- R CARBON FILM 1/6 1.2K OHM J
R930 RD-4Z620J- R CARBON FILM 1/4 62 OHM J
R931 RD-2Z279J- R CARBON FILM 1/2 2.7 OHM J
R933 RD-AZ821J- R CARBON FILM 1/6 820 OHM J
R934 RD-AZ821J- R CARBON FILM 1/6 820 OHM J
R935 RD-AZ821J- R CARBON FILM 1/6 820 OHM J
R936 RD-AZ751J- R CARBON FILM 1/6 750 OHM J
R937 RD-AZ751J- R CARBON FILM 1/6 750 OHM J
R938 RD-AZ751J- R CARBON FILM 1/6 750 OHM J
R939 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R940 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R941 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R943 RC-2Z102K- R CARBON COMP 1/2 1K OHM K
R944 RC-2Z102K- R CARBON COMP 1/2 1K OHM K
R945 RC-2Z102K- R CARBON COMP 1/2 1K OHM K
R951 RD-2Z102J- R CARBON FILM 1/2 1K OHM J
R952 RD-4Z105J- R CARBON FILM 1/4 1M OHM J
R970 RD-2Z279J- R CARBON FILM 1/2 2.7 OHM J
R971 RD-AZ123J- R CARBON FILM 1/6 12K OHM J
R972 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R973 RD-AZ273J- R CARBON FILM 1/6 27K OHM J
R974 RD-AZ223J- R CARBON FILM 1/6 22K OHM J
R975 RD-AZ470J- R CARBON FILM 1/6 47 OHM J
R976 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J
R977 RD-AZ392J- R CARBON FILM 1/6 3.9K OHM J
R978 RD-AZ563J- R CARBON FILM 1/6 56K OHM J
R979 RD-AZ182J- R CARBON FILM 1/6 1.8K OHM J
R980 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R985 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
LOC PART CODE PART NAME PART DESCRIPTION REMARK
SW8 5S50101Z90 SW TACT THVV502GDA
ZZ200 PTUNJAD713 PCB UNION AXIAL AS DSC-3261HA
A001 4859808260 PCB UNION 246X246 DIB
C902 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C908 CCZB1H561K C CERA 50V B 560PF K
C909 CCZF1H103Z C CERA 50V F 0.01MF Z
C931 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
C933 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
C953 CCZB1H820K C CERA 50V B 82PF K (AXIAL)
D901 D1N4148—- DIODE 1N4148 (TAPPING)
D902 D1N4148—- DIODE 1N4148 (TAPPING)
D903 D1N4148—- DIODE 1N4148 (TAPPING)
D904 D1N4148—- DIODE 1N4148 (TAPPING)
D905 D1N4937G— DIODE 1N4937G (TAPPING)
D906 D1N4937G— DIODE 1N4937G (TAPPING)
D907 D1N4937G— DIODE 1N4937G (TAPPING)
D908 D1N4148—- DIODE 1N4148 (TAPPING)
D909 D1N4937G— DIODE 1N4937G (TAPPING)
D910 D1N4937G— DIODE 1N4937G (TAPPING)
D923 DRGP15J—- DIODE RGP15J
D932 DUZ13BM—- DIODE ZENER UZ-13BM
J906 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J907 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J908 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J910 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J911 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J912 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J913 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J914 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J915 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J916 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J917 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J920 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J921 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J922 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J923 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J924 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J925 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J926 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J927 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J932 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J933 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JY01 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
L901 5MC0000100 COIL BEAD HC-3550
L902 5MC0000100 COIL BEAD HC-3550
L903 5MC0000100 COIL BEAD HC-3550
R901 RD-2Z100J- R CARBON FILM 1/2 10 OHM J
Part List
